spindle diameter: 130 mm

x-travel: 2240 mm

y-travel: 1600 mm

z-travel: 2000 mm

tool taper: ISO 50

max. diameter of flange turning: 0 - 1400 mm

max. diameter at boring: 800 mm

max. diameter of face turning: 0 - 1400 mm

drilling depth in one stroke: 1000 mm

faceplate diameter: 785 mm

table height: 1040 mm

table surface area: 1400 x 1600 mm

spindle turning speed range: 4,5 - 900 U/min

faceplate speeds from - to: 4,5 - 180 U/min

table load capacity: 8000 kp

table rotation: 4 x 90 °

main drive motor: 18,5 kW

electrics - voltage/frequency: 380 / 50 V/Hz

total power requirement: 30 kW

weight of the machine ca.: 35 t

dimensions of the machine ca.: 8,6 x 5,0 x 4,0 m

-
