bore capacity in steel (diameter) 40 mm
arm length 1600 mm
workpiece height max. 1250 mm
distance spindle center to column 1600 mm
spindle turning speed range 25 - 2000 U/min
feed per revolution 0,04 - 3,2 mm/U
spindle diameter 65 mm
spindle taper MT 4
quill stroke 300 mm
column diameter 350 mm
voltage 380 V
main drive 4 kW
total power requirement 9 kW
weight of the machine ca. 3 t
dimensions of the machine ca. 2,4 x 1 x 2,8 m
