Drilling capacity 10 mm
End milling capacity 10 mm
Face milling capacity 16 mm
Longitudinal axis(X) 160 mm
Cross axis(Y) 100 mm
Headstock travel(Z) 130 mm
Spindle taper MT1
Motor power 150 W
Table effective size 300x70 mm
Spindle speed Low range 100-1300 10% rpm
High range 200-2000 10% rpm
Head tilt 45°L, 45°R
T-slot size 8 mm
Overall dimension (LxWxH) 416x371x475 mm
Packing size (LxWxH) 475x415x340 mm
weight (Net/Gross) 25/28 kg
