Drilling capacity 10 mm
End milling capacity 10 mm
Face milling capacity 16 mm
Headstock travel (Z) 230 mm
Longitdinal axis (X) 180 mm
Cross axis (Y) 90 mm
Throat 140mm
Max. distance spindle to talbe 220 mm
Spindle tapger MT2
Motor output power 150 W
Spindle speed Low range 100-1000 ± 10% rpm
High range 100-2000 ± 10% rpm
Table effective size 240x145 mm
T-slot size 8 mm
Overal dimension (LxWxH) 340X320X600 mm
Weight (Net/Gross) 32/44kg
Packing size (LxWxH) 410X420X660 mm
