Drilling capacity 10 mm
End milling capacity 10 mm
Face milling capacity 16 mm
Headstock travel (Z) 230 mm
Longitudinal axis (X) 180 mm
Crpss axis (Y) 140 mm
Throat 140 mm
Head tilt 45°L, 45°R
Max. distance spindle to table 220 mm
Spindle taper MT2
Motor output power 150 w
Spindle speed Low range 100-1000 ±10% rpm
High range 100-2000 ±10% rpm
Table effective size 240x145 mm
T-slot size 8mm
Overal dimension (LxWxH) 400x320x600 mm
Weight (Net/Gross) 40/56 kg
Packing size (LxWxH) 480x400x630 mm
