Drilling capacity 13 mm
End milling capacity 16 mm
Face milling capacity 30 mm
Headstock travel (Z) 180 mm
Longitudinal axis (X) 220 mm
Cross axis (Y) 100 mm
Throat 167 mm
Max. distance spindle to table 280 mm
Head tilt 45°L, 45°R
Spindle taper MT3 or R8
Motor output power 350 w
Spindle speed Low range 100-1100 ±10% rpm
High range 100-2500 ±10% rpm
Table effective size 390x92 mm
T-slot size 12 mm
Overal dimension (LxWxH) 520x500x700 mm
Weight (Net/Gross) 50/68 kg
Packing size (LxWxH) 540x540x730 mm
