EQUIPPED WITH:
Standard Vise Assembly. Universal Dresser. Dead Center. Halogen Machine Lamp. Foot Pedal.
SPECIFICATIONS:
Largest Center Bore Diameter: 90mm/3.54"
Smallest Center Bore Diameter: 2mm/.078"
Taper Angle of Center Hole: 60°-90°
Maximum Length of Workpiece: 1200mm/47.24"
Maximum Clamping Range of Vise: 160mm/6.3"
Minimum Clamping Range of Vise: 5mm/.19"
Maximum Weight of Workpiece: 190kg
Maximum Flange Diameter or Workpiece: 15"
Maximum Lift of the Wheelhead: 150mm/3.93"
Diameter of the Grinding Stones: 10, 20, 32mm
Speed of Grinding Spindle: 26,000 RPM
Eccentric Speed: 50 RPM
Electrics: 3 Phase, 60 Cycle, 460 Volt
