Type: 1600mm*6000mm*50T
Distance between Centers (L): ≥5m (1m increment)
Roll Measuring Range Dia (mm): 300-1600
Workpiece Weight Max (t): 50
Grinding stock Travel (mm):900
Curve Height Max (mm): ±2 (radius)
Grinding Wheel Specification (mm):900×100×305
Grinding Wheel Linear Speed (m/s): ≤45
Headstock Speed Range (rpm)： 5-50
Carriage Travel Speed (mm/min): ≤6000
Grinding Wheel Motor Power (kW): 100
Grinding Max (kg/h): 100
Curve Grinding Accuracy (mm): 0.002
Machine Numerical Control System: SIEMENS 840D
AC Servo Axis Number: X, U, Z, X1, U1, V
AC Spindle Number: Grinding Wheel, Headstock
HMI Weight (t): 135(6m)
Machine Profile Size (cm):1335×550×300

Type: MK84160-Ⅲ50
Distance between Centers (L): ≥5m (1m increment)
Roll Measuring Range Dia (mm): 300-1600
Workpiece Weight Max (t): 50
Grinding stock Travel (mm):900
Curve Height Max (mm): ±2 (radius)
Grinding Wheel Specification (mm):900×100×305
Grinding Wheel Linear Speed (m/s): ≤45
Headstock Speed Range (rpm)： 5-50
Carriage Travel Speed (mm/min): ≤6000
Grinding Wheel Motor Power (kW): 100
Grinding Max (kg/h): 100
Curve Grinding Accuracy (mm): 0.002
Machine Numerical Control System: SIEMENS 840D
AC Servo Axis Number: X, U, Z, X1, U1, V
AC Spindle Number: Grinding Wheel, Headstock
HMI Weight (t): 135(6m)
Machine Profile Size (cm):1335×550×300
