Type: MK84250-Ⅲ200
Distance between Centers (L): ≥8m (1m increment)
Roll Measuring Range Dia (mm): 850-2500
Workpiece Weight Max (t): 200
Grinding stock Travel (mm):900
Curve Height Max (mm): ±2 (radius)
Grinding Wheel Specification (mm):1066×150×305
Grinding Wheel Linear Speed (m/s): ≤45
Headstock Speed Range (rpm)： 2-25
Carriage Travel Speed (mm/min): ≤12000
Grinding Wheel Motor Power (kW): 179
Grinding Max (kg/h): 170
Curve Grinding Accuracy (mm): 0.002
Machine Numerical Control System: SIEMENS 840D
AC Servo Axis Number: X, U, Z, X1, U1, V
AC Spindle Number: Grinding Wheel, Headstock
HMI Weight (t): 260(8m)
Machine Profile Size (cm):1800×700×400
