Motor power: 0,55 / 0,75 KW 380 Volt 50Hz
2 spindle speeds: 3750 -7500 rpm
max. Workpiece diam such spikes 130 mm
max. Workpiece diam flying curious: 320 mm
ma grinding length 250 mm
Inner cone d. dividing head spindle: Normkegel 40 ( SK 40 )
Tischschlittenbeweg: 260 mm
D. table swivel slide: 360
Dividing head carriage movement: 100 mm
Cl / Gr. erziehlbare twist pitch 10 mm -6800
Dimensions: lg: 1080 W: 850 mm H: 1460 mm
Weight: approx 450 kg
Accessories: dust extraction, extractor, Spiralschleifeinr. with disks, removable disks part, various pins and discs with recordings, and various small vise, collets with food
