SPECIALPRICE***UNUSED MACHINE WITH PARTS WARRANTY**

turning diameter over bed 500 mm
turning diameter over slide rest 290 mm
turning length 2000 mm
length of gap 250 mm
turning dia. in gap 760 mm
bed width 394 mm
spindle taper D1-8
spindle bore 105 mm
spindle turning speed range 26-1700 U/min
transmission ratio 16 Stck.
metrical thread cutting 0.35-80 mm/U
threading WHITWORTH 7/16-80 TPI
diameter of quill 75 mm
longitudinal feed 0,044-1,48 mm/U
cross feed 0,022-0,74 mm/U
taper of spindle bore 1100/1:20 MK
range of module thread 0,2-40 mm
range of dimetrical thread 7/8-160 DP
power requirement 11 kW
weight of the machine ca. 2200 kg

-
