Height: 200 mm
Centers: 1000 mm
Turning diameter over bed: 400 mm
Turning diameter over support 220 mm
Spindle Bore: 52 mm
Speed ​​range: 9-1600 rpm
Spindle nose: Bayonet DIN 5027 KK 6
Longitudinal feeds range: 0.028 to 6.43 mm / rev (93 steps)
Area cross feeds: 0.012 -2.73 mm / rev (93 steps)
Metric threads: 0.5 - 224 (48 steps)
Inch threads: 72 - 1 / 8 tpi (46 steps)
Module pitch: 0.5 - 112 (42 steps)
Diametral thread: 56 - 1 / 4 DP
Quill diameter: 75 mm
Spindle stroke: 150 mm
Taper: Morse taper 5
Motor power: 7.5 kW
Weight: 2100 kg
Dimensions: 2672 x 975 x 1230 mm
Accessories: Digital display for 3-axis mark SINO, 3-jaw chuck Ø 250 mm, 4-jaw faceplate chuck Ø 400 mm, fixed + follow rest, coolant system, fire wall, rapid, manual lubrication, 4-way tool operating light.

-
