Swing over bed 140 mm
Distance between centers 250 mm
Hole through spindle 10 mm
Spindle taper MT2
Tailstock taper MT1
Spindle speed 100-2000 ±10% rpm
Cross slide travel 50 mm
Motor output power 150 W
Range of threads Metric version 0.5-1.25 mm (5 thread pitches)
Imperial version 16-24 TPI (5 thread pitches)
Overall dimension (LxWxH) 620x300x220 mm
Weight (Net/Gross) 23/32 kg
Packing size (LxWxH) 680x350x390 mm
