Swing over bed 180 mm
Distance between centers
Model 200
200 mm
Model 300 300 mm
Hole through spindle 20 mm
Cross slide travel 65 mm
Compound travel 55 mm
Spindle taper MT3
Tailstock taper MT2
Spindle speed Low range 100-1100 ±10% rpm
High range 100-2500 ±10% rpm
Motor output power 250 W
Range of threads Metric version 0.4-2.0 mm (10 thread pitches)
Imperial version 12-52 TPI (18 thread pitches)
Overall dimension(LxWxH) Model200 620x300x290 mm
Model 300 720x300x290 mm
Weight(Net/Gross) Model 200 33/36 kg
Model 300 37/40 kg
Packing size (LxWxH) Model 200 670x330x330 mm
Model 300 790x360x380 mm
