Swing over bed 180 mm
Distance between centers Model 300 300 mm
Model 350 350 mm
Hole through spindle 20 mm
Cross slide travel 65 mm
Compound travel 55 mm
Spindle taper MT3
Tailstock taper MT2
Spindle speed (variable speed) 100-2500 ±10% rpm
Motor output power(Brushless motor) 500 W
Range of threads Metric version 0.4-2.0 mm (10 thread pitches)
Imperial version 12-52 TPI (18 thread pitches)
Overall dimension Model 300 720x300x290 mm
Model 350 800x290x290 mm
Weight(Net/Gross) Model 300 44/51 kg
Model 350 50/55 kg
Packing size (LxWxH) Model 300 780x420x390 mm
Model 350 870x360x380 mm
