Swing over bed 180 mm
Cross slide travel 65 mm
Compound travel 55mm
Motor output power 350 W
Distance between centers 350 mm
Hole through spindle 20 mm
Spindle taper MT3
Tailstock taper MT2
Spindle speed Low range 100-1200 ±10% rpm
High range 100-3000 ±10% rpm
Thread of range Metric version 0.4-2.0 mm (10 threads pitches)
Imperial version 12-52 TPI (18 threads pitches)
Overall dimension (LxWxH) 800x290x290 mm
Weight (Net/Gross) 44/50 kg
Packing Size (LxWxH) 870x360x380 mm
