Swing over bed 210 mm
Distance between centers 410 mm
Hole through spindle 20 mm
Spindle taper MT3
Tailstock taper MT2
Spindle speed (variable speed) 150-2000 ±10% rpm
Compound travel 70 mm
Cross slide travel 100 mm
Motor output power 1000 W
Thread of range Metric 0.25-3.0 mm (17 Threads pitches)
Imperial 8-24 TPI (10 Threads pitches)
Overall dimension (LxWxH) 1000x550x400 mm
Weight (Net/Gross) 90/117kg
Packing Size (LxWxH) 1070x710x530 mm
