Swing over bed 210mm
Distance between center Model 400 410mm
Model 550 550mm
Hole through spindle 20mm
Spindle taper MT3
Spindle speed (6 steps) 100-2000 rpm
Tailstock taper MT2
Thread of range C4A Metric version 0.4-3.0 mm (12 Threads pitches)
Imperial version 10-44TPI (8 Threads pitches)
C4B Metric version 0.4-3.5 mm (15 Threads pitches)
Imperial version 7-44 TPI (12 Threads pitches)
Cross slide travel 100mm
compound travel 70mm
Motor output power 550W
Weight (Net/Gross) C4A 90/117kg
C4B 94/121kg
Packing size(L×W×H) 1070×730×570mm
