Swing over bed 250 mm
Distance between centers Model 400 400 mm
Model 550 550 mm
Hole through spindle 20 mm
Spindle taper MT3
Tailstock taper MT2
Spindle speed(6 step) 125-2000 rpm
Compound travel 75 mm
Cross slide travel 110 mm
Motor output power 550 W
Thread of range Metric version 0.4-3.0 mm (12 threads pitches)
Imperial version 10-44 TPI ( 8 threads pitches)
Overall dimension (LxWxH) Model 400 1040x600x450 mm
Model 550 1140x600x450 mm
Weight (Net/Gross) Model 400 125/160 kg
Model 550 145/180 kg
Packing size (LxWxH) Model 400 1040x640x570 mm
Model 550 1200x640x570 mm
