Upper and Lowet Turrets with Twin Opposed Spindles, Collet Chucks for Main and Sub Spindle, Automatic Tool Setter, Auto Parts Catcher for Sub Spindle, Rigid Tapping, Chip Conveyor, Servo Driven Turrets, Three Color Tower Light, Remote Manual Pulse Generator, Short Magazine Barfeed, Slant Bed Box Way Construction
Specifications:
Chuck Size 10"
Max Diameter Bar Capacity 3"
Max Swing Over Bed / Carriage 30.7" / 27.5"
Max Turning Diameter (Upper / Lower) 15.4" / 11.8"
Max Machining Length 36.2"
Main Motor 33.5 / 25 HP
Tools 12 / 12
Spindle Speed 4000 RPM
Spindle Bore 3.4"
Spindle Nose A2-8
Spindle Torque 319.4 ft. lbs.
Rapid Traverse Rates (X & Z / Y) 945 / 472 IPM
X-Axis Travel (Upper / Lower Turret) 10.6" / 36.2"
Z-Axis Travel (Upper / Lower Turret) 7.5" / 36.2"
Y-Axis Travel +/- 2.4"
C-Axis Index (Main & Sub Spindle) .001 Degree
Sub Spindle Chuck Size 10"
Sub Spindle Bar Capacity 3"
Sub Spindle Motor 15 / 10 HP
Sub Spindle Speed 4000 RPM
Turret Index (Single Step) 0.2 Seconds
Machine Dimensions (L x W x H) 144.5" x 85.4" x 100.4"
Machine Weight 24,251 lbs.
FEATURES:
FANUC 18i-TB CNC CONTROL
10.4" Color LCD
Upper and Lower Turrets with Twin Opposed Spindles
Collet Chucks for Main and Sub Spindle
Automatic Tool Setter
Auto Parts Catcher for Sub Spindle
Rigid Tapping
Chip Conveyor
Servo Driven Turrets
Three Color Tower Light
Remote Manual Pulse Generator
Short Magazine Barfeed
Slant Bed Box Way Construction
