max. Slide travel: 470 mm max. Bettschlittenweg: 1000 mm Height over cross slide: 132 mm max. Shooting at knife-head circle S 240: 300 mm max. Shooting at knife-head circle S 350: 255 mm Spindle nose: DIN 55026: Size 8 spindle capacity Dimensions: 103 mm forward in the draft tube: 91 mm Main bearing diameter: 140 mm quill stroke: 200 mm Quill diameter: 90 mm taper: 5 MK largest chuck diameter: 250 mm Max turning tool -Qürschnitt: 10-2240 1/min: 25 x 25 mm spindle rotation speed. Polygon drive speed max. 1200 mm switchable transmission stages: (only for spindle rotation): 3 feed Z-axis: 0.001 to 50 mm / rev rapid Z-axis: min 8000 mm /. Feed X-axis: 0.001 to 50 mm / rev rapid traverse X-axis: min 4000 mm /. Longitudinal pitch: 0.001 to 400 mm / rev Feed drives: infinitely variable main drive variable DC power: 26 kW
