Technical data: Max. Swing diameter 230 mm standard machining diameter mm 230 Max. Bar diameter mm 51 Travel X Axis mm min-1 200 Travel Z left / right mm 365/420 Y-axis travel mm 80 (40) Rapid XZ axis m / min 30/33 Rapid traverse Y axis m / min for 15 Rapids C axis 400 Number headstocks 2 speed range min-1 6000 Main drive power (25%. / 100%) kW AC 11 / 7.5 spindle bore mm 61 C axis degree 0.001 Hydraulic 3-jaw chuck SMW 210 mm turret with driven Wkz. number Turret 2 Number of places 12 tool shank height mm 20 mm 32 Bohrstangenschaftdurchmesser Driven tools speeds (10 min. ED) min-1 4500 kW AC drive power 3.7 Dimensions (LxWxH) 300 x 165 cm x 210 Weight kg 6500
