10" Hydraulic Chuck, Programmable Tailstock, Chip Conveyor (Side Exit), Two Gear Range Headstock, Slant Bed Box Way Construction
Specifications:
Chuck Size 10"
Max Diameter Bar Capacity 2.9"
Max Swing Over Bed / Carriage 20.5" / 13.7"
Max Turning Diameter 14.9" / 11.42"
Distance Between Centers 25.6"
Max Machining Length 24"
Spindle Speed 3500 RPM
Spindle Bore 3.5"
Spindle Nose A2-8
Spindle Motor 25 / 20 HP
Spindle Torque 251.5 ft. lbs.
Tools 10
Rapid Traverse Rates (X / Z) 472 / 590 IPM
X-Axis Travel 9.44"
Z-Axis Travel 33.6"
Tailstock Taper MT#4
Machine Dimensions (L x W x H) 118.8" x 68.7" x 76.4"
Machine Weight 11,880 lbs.
FEATURES:
FANUC 0-T CNC CONTROL
9" Monochrome CRT
10" Hydraulic Chuck
Programmable Tailstock
Chip Conveyor (Side Exit)
Two Gear Range Headstock
Slant Bed Box Way Construction
