Machine is in excellent condition, as it was only used 10% of the time.
There is no chuck with the machine.
The machine has no turret but a swiveling drilling and milling unit.
turning diameter 1600 mm
turning length 3400 mm
control H&D
Swing over Gap 2900 mm
Center height over bed 870 mm
Swing over bed 1670 mm
Swing over cross slide 1310
Spindle power 55 kW
Spindle RPM 2,24 - 710 1/min
Gear steps 2
Max. torque at the spindle 12.500 Nm
spindle bore 128 mm
Spindle bearing diameter 240 mm
Bed width 710 mm
Rapid traverse 6 m/min
Tailstock quill taper metric 6 MK
Dia. of quill 200 mm
Quill stroke 350 mm
Max. workpiece weight -without tailstock 2500 kg
Max. workpiece weight between centres 6300 kg
Drilling an milling unit Power 17 kW
Drilling and milling unit torque 260 Nm
Tool type Capto C6
