turning diameter over bed : 460 mm
turning diameter over cross slide : 258 mm

center height : 225 mm
distance between the tip : 1000 mm

bed wideness : 300 mm

spindle :
speed range
L : 95 - 350 U / min
M : 250 - 1000 U / min
H : D1 - 6 : 690 - 3.000 U / min
H : D1 - 8 : 690 - 2.500 U / min
spindle nose : ASA D1 -6"
spindle bore : 58 / 78 mm
driving power spindle motor : 7,5 / 9,3 kW

working stroke
longitudinal direction : 580 mm
transverse direction : 210 mm

feed force:
longitudinal direction : 5000 N
transverse direction : 2400 N

rapid traverse : 5 m / min

carriage:
travel: 127 mm
wide : 110 mm

tailstock
quill diameter : 68 mm
travel pinole : 127 mm
recording : MT4

mass of the machine:
machine length : 2500 mm
machine wide : 1350 mm
machine height: 1800 mm
weigth: 1700 / 1790 kg

10.4" color LCD
preparation for multifix
9" three jaw chuck
10" four jaw chuck
rotading center

-
