turning diameter over bed : 460 mm
turning diamtere over cross slides : 258 mm
top height : 225 mm
distance between tips : 1000 mm
bed range : 300 mm
spindle speed range :
L: 95 - 350 U / min
M: 250 - 1000 U / min
H: D1 - 8 : 690 - 3.000 U / min
H: D1 - 8 : 690 - 2.500 U / min
spindle nose : ASA D1 - 6"
spindle drilling : 58 / 78 mm
driving power spindle motor : 7,5 / 9,3 kW
working stroke longitudinal direction : 580 mm
transverse direction : 2400 N
rapid traverse : 5 m / min (continously)
carriage travel : 127 mm
width : 110 mm
diameter sleeve : 68 mm
travel sleeve : 127 mm
mounting : MT4
length of the machine : 2500 mm
width of the machine : 1350 mm
height of the machine : 1800 mm
weight : 1700 / 1790 kg

-
