Swing over bed 17"
Swing over cross slide 10 9/16"
Swing in gap 24"
Distance between centers 67"
Spindle speeds (12) 35 - 2000
Feed range (16) .0012 - .034 inch/rev.
Thread range
English (44) 2 - 72 tpi
Metric (39) .2 - 14 mm pitch
Spindle nose D1-6
Spindle thru hole 2 1/4"
Tailstock quill diameter 2 3/8"
Tailstock taper MT #4
Drive motor 7 1/2 HP
Dimensions 110" x 39" x 47" high
Weight 4,100 lbs.
