Max. turning diameter 1250mm
Table diameter 1000mm
Max. working height of workpiece 1000mm
Max. weight of workpiece 3.2t
Speed range of table 6.3-200r/min
Speed-step of table 16 steps
Max. torque of table 17.5KN.m
Max. cutting force of railhead 20KN
Max. cutting force of sidehead 20KN
Total cutting force 35KN
Horizontal travel of railhead 700mm
Vertical travel of railhead 650mm
Horizontal travel of sidehead 630mm
Vertical travel of sidehead 900mm
travel of crossbeam 650mm
Moving degrees limit of railhead ±30°
Feed range of railhead/sidehead 0.8-86mm/min
Rapid traveling speed of railhead/sidehead 1800mm
Traveling speed of crossbeam 440mm
Power of main motor 22KW
Overall dimension of machine 2360×2270×2800mm
Weight of machine 9 T
Specifications:
Max. turning diameter 1250mm
Table diameter 1000mm
Max. working height of workpiece 1000mm
Max. weight of workpiece 3.2t
Speed range of table 6.3-200r/min
Speed-step of table 16 steps
Max. torque of table 17.5KN.m
Max. cutting force of railhead 20KN
Max. cutting force of sidehead 20KN
Total cutting force 35KN
Horizontal travel of railhead 700mm
Vertical travel of railhead 650mm
Horizontal travel of sidehead 630mm
Vertical travel of sidehead 900mm
travel of crossbeam 650mm
Moving degrees limit of railhead ±30°
Feed range of railhead/sidehead 0.8-86mm/min
Rapid traveling speed of railhead/sidehead 1800mm
Traveling speed of crossbeam 440mm
Power of main motor 22KW
Overall dimension of machine 2360×2270×2800mm
Weight of machine 9 T
