48" G&L Model 512, CNC VTL,4 Jaw power chuck, coolant, 800 control, Excellant
Specifications:
Used Giddings & Lewis Model 512, Vertical Turret Lathe, New 1982
Specifications:
Table 4-Jaw Dual Pressure Hyd.
Size 48”
Speeds 2 Ranges 4 to 400 RPM
Turret Head 5 Positions
Rotation C.W. or C.C.W.
Travel 36”
Feed Ranges .01 to 100 IPM
Rapid Traverse 250 IPM
Max Swing Dia 60”
Max Height Under Cross Rail 48”
Max Weight on Table 185,000 at 32 RPM; 100,000 at Max RPM
Table Drive 75 HP 30 Min
Equipped With:
Pendant Control
2 Axis CNC
G & L 800
Thread Cutting
Tape Punch Interface
Flood Coolant with guards
Stub Chip Conveyor
