MAXIMUM SWING 52”
TABLE SIZE 42”
MAX. HEIGHT UNDER RAIL HEAD SADDLE 36”
TURRET STATIONS 5
MAX. HEIGHT UNDER TURRET HEAD TURRET BLOCK 42”
TURRET SLIDE TRAVEL BELOW SADDLE 24”
TURRET SLIDE TRAVEL ABOVE SADDLE 6”
TURRET HEAD TRAVEL TO TABLE CENTER 29”
TURRET HEAD TRAVEL PAST TABLE CENTER 29”
MIN. HOLE TURRET SLIDE WILL ENTER 30”
TURRET BLOCK BORES 2-3/4”
SPEED RANGES 2
LOW RANGE 3.1 - 164 RPM
HIGH RANGE 9.3 - 486 RPM
FEED RANGE .5 - 60 IPM
RAPID TRAVERSE RATE 200 IPM
SPINDLE MOTOR 75 HP
TERMS: SPECIFICATIONS AND EQUIPMENT LISTED SUBJECT TO VERIFICATION
