Extremely heavy duty built machine. Available for install about July 15th, 2012

AMERA-SEIKI VB-4 BRIDGE MILL

TRAVEL;

Longitudinal Travel (X) 165”
Cross Travel (Y) 79”
Headstock Travel (Z) 35”
Distance Between Columns 78.75”
Spindle Nose to Table 2-37”

TABLE;

Length 165”
Width 65”
T-Slots Size .866”
Center Distance 6.69”
T-Slots Number 9
Max Table Load 17,640 lbs.

SPINDLE ;

Spindle Speeds 30~6000rpm
Spindle Nose CAT 50

MOTORS;

Spindle Motor 30 HP

Drive Motor X Axis 12 HP
Y Axis 9 HP
Z Axis 9 HP



CONTROL;

Fanuc 0i-MD, w/10.4 Color Screen, Manual Guide I


TOOLING;

Max Tool OD 5”
Max Tool Length 14”
Max Tool Weight 44.1 lbs
Tool selectionBi-Directional
ATC Changer 32 Tools

GENERAL;

Machine Dimensions433”x169”x176”
Net Weight76,000 lbs.
Base Size472” x 197”

FEEDRATE;

Rapid Traverse (X/Y/Z) 472 ‘’/ min.
Cutting Feedrate 1~ 393.70’’/ min.

STANDARD OPTIONS;

30 HP Motor
2 Speed ZF Gear Box
Oil Coolant thru ballscrews
Chip Conveyer
Oil Skimmer
Thru Spindle Coolant- 300 PSI.
Extra Coolant System, 105.6 Gallon, w/paper filter (21gal/min)

66000
