Fully automated 5-axis machining cell for the production of turbine blades and shafts from blank billets - Make StarragHeckert consisting of a CNC horizontal machining center Make Heckert SX-051B, Year 2004 Amenities: ------------ - CNC Control Siemens 840D - min main spindle 15,000 rpm / 19 kW - - tilting table with an interface for the construction of circular station and tailstock - Round Station with Power Take-Two jaw chuck - swivel tailstock 60-fold tool changer, HSK 63 - coolant through the spindle, high pressure pump, Vakuumspaltsieb and backwash - Chip conveyor - compressor refrigeration for cooling the work spindle and the rotary axes - hand washing with flushing gun - protects all components - steam exhaust device - Rotating lens - process oriented fairs Technical Details: ------------------- X axis 650 mm Y-axis 650 mm Z-axis 600 mm A-axis degree endless 155 degree B-axis tool change chip-to-Span's feed 5 mm / min rapid traverse 0 40,000 m / min 40 max. Speed r / min - 15,000 drive power (100 / 40%) 19/31 kW rapid traverse (X / Z-axis), m / min 60/30 workpiece dimensions (length / diameter) 400/220 mm Machine dimensions (LxWxH) mm 4.600x3. 920x3.000 Machine weight kg 12 800 1 palletizing and stacking module - with 2 NC linear axes, and multi-function gripper - car guide and fuser - Security panel with 4 roller doors in cars run one direction and - Access door in de [...Technical data truncated]
