24 Position Side Mount Tool Changer, Coolant Thru Spindle, 12000 RPM Spindle Speed, Spindle Chiller Unit, Yellow Operating Condition Light, Rigid Tapping, 2100 ft. (640 M) Memory, Helical Interpolation
Specifications:
Travel: X-Axis 31.5"
Y-Axis 18.1"
Z-Axis 20.5"
Table Size 39.37" x 18.11"
Spindle Speed 12000 RPM
Spindle Taper BT 40
Spindle Nose to Table Top 4.9" - 25.4"
Spindle Motor 20 / 15 HP
Spindle Torque 70.5 ft. lbs.
Tools 24
Table Load Capacity 1323 lbs.
Rapid Traverse Rates 1260 IPM
Tool Change Time (T - T / C - C) 1.5 / 5.2 Seconds
Max Tool Diameter 3.5" / 5.9"
Max Tool Length 11.8"
Max Tool Weight 17.6 lbs.
Machine Dimensions (L x W) 120.1" x 82.7"
Machine Weight 11,023 lbs.
FEATURES:
FANUC 0i-M CNC CONTROL
8.4" Color LCD
24 Position Side Mount Tool Changer
Coolant Thru Spindle (230 psi)
12000 RPM Spindle Speed
Spindle Chiller Unit
Yellow Operating Condition Light
Rigid Tapping
2100 ft. (640 M) Memory
Helical Interpolation
