High Speed Graphite Machining Center with Dust Extraction System
Specifications:
Travels X- 23.6” Y- 11.8” x Z- 5.9” . Z-axis travel is restricted by design. Z- axis is exposed to enormous oscillating forces when operating at high speeds.
The granite work table is adjustable using holes set at 50 mm intervals and then finely adjusted
Workpiece weight 440#
SC -62 Spindle Speed 60,000 RPM
Dust Collection System,
Refrigerated spindle,
Glass scales
Fully guarded Enclosure.
All axis run on hardened polished ways with turcite counterstays
Machine is built using a 3-axis cross slide principle
on a fixed polymer concrete structure open at the top with a granite work table.
