30 Position Side Mount Tool Changer, Spindle Chiller Unit, Table Chip Guards, Remote Manual Pulse Generator, Two Gear Range Headstock, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 41.34"
Y-Axis 23.62"
Z-Axis 22.05"
Table Size 55.12" x 23.62"
Spindle Speed 10 - 3500 RPM
Spindle Taper Cat 50
Spindle Nose to Table Top 8.87" - 30.87"
Spindle Motor 15 HP
Tools 30
Table Load Capacity 3300 lbs.
Rapid Traverse Rates 472 IPM
Max Tool Diameter 5.7"
Max Tool Length 16"
Max Tool Weight 33 lbs.
Machine Dimensions (L x W x H) 142" x 165" x 119"
Machine Weight 19,400 lbs.
FEATURES:
FANUC 0M CNC CONTROL
12" Color CRT
30 Position Side Mount Tool Changer
Spindle Chiller Unit
Table Chip Guards
Remote Manual Pulse Generator
Two Gear Range Headstock
Heavy Duty Box Way Construction
