Factory No. 12896/56401
EK 1 - 283/64
Year 1964
Range:
without moving the table 250 x 200 mm
max. Distance for Fraessp .- bottom edge and router table surface 350 mm
Vertical movement v. Fraessp. Copy and pin 70 mm
Distance between cutter and indelible pencil 350 mm
Spindle taper Interior 1: 10
Router table surface 350 x 450 mm
Model table area 350 x 450 mm
Footprint 1.40 m x 0,90 m
Height: 1.80 m
Weight: 1500kg
Rpm rpm
Engine rpm: 1400
Level 1 - 2: 400-2750
Level 3 - 4: 1450-10000
380 V 0.8 Kw / 1410 rpm
