Factory No. 13519/56703-328
Workspace
gr.Entf.v.Arbeitssp.b.Aufspannflaeche 600 mm
max. Adjustability of the boom vertically 420 mm
max. Movement of the boom across 500 mm
max. Movement along the Mill attachment 400 mm
Distance between spindle and indelible pencil 500 mm
Adjustability of the vertical spindle 80 mm
max. Amount of dividends to mill workpieces 500 mm
Spindle taper - Inside 1:10
max. Cutter diameter 22 mm
Router table clamping area 550 x 625 mm
T-Slot: Number 8, width 16 mm, 69 mm distance
Vertical movement of hand 300 mm
Longitudinal movement of hand 300 mm
Transverse movement of hand 400 mm
Copy table clamping area 550 x 625 mm
Motor speed: 1400 380 V / 50 Hz
Serving Level 1 - 2: 400-2700
Serving Level 3 - 4: 1440-10000
1.5 kW
Space required: 2.45 x 1.35 m
Height: 2.58 m
Weight: 2800 kg

-
