Table Size : 305 x 305 mm
Table Circuit : 0,001°
Max. Loading Weight : 250 kg
Travel Longitudinal ( X - Axis) : 400 mm
Travel Across ( Y - Axis ) : 425 mm
Vertical ( Z - Axis ) : 400 mm
Distance Table top - Spindle head: 100 - 500 mm
Distance Stand - Table Centre line : 50 - 475 mm
Spindle taper : NST Nr. 40
Speed : 100 - 10000 mm / min
Drive : belt drive
Feed Rapid traverse (X,Y,Z - axis) 24 m / min
Cutting feed ( X,Y,Z ) 0 - 10.000 mm / min
Tool memory : 100
Tool selection : Direct Control
Tool holder : MAS BT 40 / CAT 40
Max. Tool size ( o x L ) 95 x 350 mm
Adjacent tool station ( empty) 140 x 350 mm
Max. Tool weight: 10 kg
Tool change time : 1,7 sec
Chip to Chip : 7,0 sec
Positioning accuracy : 0,003 mm
Repeatability : 0,001 mm
Spindle motor : AC 9.0 / 5.5 KW
Dimensions : 2,1 x 2,9 x 2,7 m
Machine weight : 7.750 kg

-
