Technical Data:
Milling width: 1250 mm
Milling hight: 1720 mm
Milling length : 4000 mm
Width between Colums: 1860 mm
Clearance hight max.: 1600 mm
Table size: 4200 x 1250 mm
max. Workpice weight: 13 t
Table feed , stepless 4 – 6000 mm/min
Movement Cross beam 5 - 750 mm / min
Dimensions / Weight:
Width: 7000 mm
Hight: 5960 mm
Length: 13000 mm
Weight: 56000 KG
Milling Support:
Cross rail
Power: 32 kW
Drive speed: 11 – 900 min-1
Side support
Power: 32 kW
Drive speed: 11 – 900 min-1
Subject to prior sale and errors concerning technical data
