x-travel: 6000 mm

y-travel: 1700 mm

z-travel: 600 mm

spindle taper: ISO50

turning speeds: 6...115+116...1800 rpm

feed:0...3000 mm/min

rapid traverse: ...6000 mm/min

feed at: x=0...3000 mm/min

clamping plate: 2000x7500 mm

distance spindle nose and tablehoriz.: 320-920 mm

distance spindle nose and tablevertic.: 180-780 mm

daylight between the columns: 1830 mm

total power requirement: 18 kW

weight of the machine ca.: 30,0 t

-
