Vertical&Horizontal Turret Milling Machine

Spindle taper

ISO 40

Spindle travel

150mm

Distance from spindle to column

200~600mm(V)

Distance from spindle to table

155~455mm(V)
0~300mm(H)

Range fo spindle speed

20step 76~6980rpm(V)
12step 60~1350rpm(H)

Size lf table surface

1250×320mm

Table travel(X、Y、Z)

800×300×300mm

T-slot (number-width-distance)

3/14mm/70mm

Main motor power

3.7KW(V);2KW(H)

Overall dimension

1820×1520×2270mm

N、W、/G、W、

1850/2050kg
