ravel:
X-axis: 1800 mm
Y-axis: 600 mm
Z-axis: 900 mm
Table dimensions: 2500x575 mm
max. Workpiece weight: 3000 kg
T-slots: 3 pieces
T-Slot width: 22 mm
T-slot spacing: 152 mm
feeds:
X-axis: 20-2200 mm / min
Y-axis: 20-2200 mm / min
Z-axis: 12-1320 mm / min
Rapid feed:
X-axis: 3000 mm / min
Y-axis: 3000 mm / min
Z-axis: 1800 mm / min
Speed ​​range: 40 - 1200 min-1
Spindle taper: ISO 50
Distance spindle nose to table surface: 50 - 950 mm
Head swivel range: 360 °
Main drive motor power: 11 kW
Power feed: 2.9 kW
Coolant pump motor power: 0,09 kW
Dimensions: 4300x3200x3300 mm
Weight: 12000 kg

-
