Heidenhain TNC 426 control clamping surface 6500x1200mm X / Y / Z: 6000/1500/1500mm speed range 50 3,000 r / min main drive AC motor 30 kW T-slot spacing 100 mm T-slots Quantity + Size 10 x 22 H7 table edge watermark receptive-Y head horiz. : -265 / +1235 mm table edge Wz-Z recording head horiz. -80 / +1420 mm Tischoberfl. Wz spindle head vertical center-Y: -300 / +1200 mm Tischoberfl. Wz-spindle center Z head vertical: -115 / +1385 mm tool taper iso 50, DIN 69871 AD tool weight: 20kg Max Tool in chain 125mm Max Tool in chain 250mm without adjacent tool changer 60-fold cooling through spindle coolant system swivel head with filter 2.5 Spare parts package
