Table size 1800x500 mm
Speeds 45-1800 U / min 17 steps
max. Table load 1500 kg
Travel X-axis manual / automatic 1330/1320 mm
Y-axis manual / automatic 360/345 mm
Travel Z-axis manual / automatic 630/600 mm
Toolholder taper ISO 50
90 mm quill travel
Swivel range + -45 ° on both sides
min / max distance spindle nose - table 95-725 mm
Throat 450 mm
X + Y axis feed 16-800 mm / min 18 steps
X + Y axis rapid traverse 3000 mm / min
Feed Z axis 5-250 mm / min 18 steps
Min rapid traverse Z axis 1000 mm /
Engine power 15 kW / 400 volts
Port value of 25 KVA
Number / size of clamping grooves 6x18x63
Weight 5500 kg
Dimensions 2530x2194x2595 mm

-
