Specifications: Control: AC-vision Hours: 99 549 EDM hours: 39280 Completed maintenance, repairs (period): Y-spindle 02.2011 renewed, Z buttons and back panel gasket; Monitor at 15 altered manuals available space machine (LxWxH) 2215mm X 2320mm X Loading measurements 2280mm machine (LxWxH) 2215mm x 2320mm x 2280mm processing mass X-axis = 350 mm Y-axis = 250 mm Z-axis = 256 mm max. Workpiece dimensions: Length: 750 mm Width: 550 mm Height: 250 mm Machine Weight: 3600kg
