sheet width - max. 400 mm
coil weight 3,2 t
coil internal dia. mm
coil outside dia. max. 1600 mm
plate thickness 0,5 - 3 mm
diameter of the mandrel min. ca. 500 mm
swivellable 0 - 45 °
total power requirement 4,4 kW
weight of the machine ca. ca. 4,5 t
dimensions of the machine ca. 2,43 x 1,9 x 2,5 m
Electric 380 Volt

Motorized tilting up to 45 degrees, pressure arm pneumatic, spreading by manually crank, coil drive = feed
electrically brake motor with clutch and disc brake.
