X - axis mm 610 Y - axis mm 455 Z - axis mm 510 Machine table table mm 760 x 360 T - slot number 4 T - slot width mm 16 T - slot distance 80 mm distance table - spindle nose mm / minimum 110 mm / maximum 620 Distance spindle center - stand 450 mm Table load capacity 350 kg table height from ground 800 mm headstock spindle taper ISO / ISO 40 tool holder MAS BT 40 tool tray pin ISO 7388 A AC - main drive Fanuc S6/40% kW 7.5 Spindle speed r / min 10000 Torque nm 48 drive stepless belt drive tool magazine page changer with double gripper and directional logic, BT-40 magazine positions number 20 tool coding variable space coding tool weight maximum of 6 kg tool length up to 200 mm tool diameter up to 75 mm tool diameter max / free adjacent pockets) mm 125 tool change time sec 2.5 [...Technical data truncated]
