Max Stroke: 365mm Max Pressure: 340 Bar Brake Time: 95ms Safety distance min:190mm weight:9950kg Pneumatic connection: 6bar

Travel: Axis 23.62"
Y-Axis 16.14"
Z-Axis 20.08"
Table Size 29.53" x 14.17"
Spindle Speed 6000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 3.9" - 24"
Spindle Motor 15 / 10 HP
Tools 16
Table Load Capacity 770 lbs.
Rapid Traverse Rates 1181 IPM
Max Tool Diameter 3.5"
Max Tool Length 9.84"
Max Tool Weight 13.2 lbs.
Machine Weight 8300 lbs.

FEATURES:
MITSUBISHI CNC CONTROL
9" Monochrome CRT
Indexer Interface
Remote Manual Pulse Generator
Rigid Tapping
Helical Interpolation
Full Enclosure

9950KG
