drilling capacity in steel 50 mm

drilling capacity in cast iron 65 mm

drilling capability in steel 65 mm

thread cutting in steel ST60 M60

thread cutting in cast iron M72

spindle fixture MK 5

spindle speeds continuously variable by intermediate gear
from 63 to 1,250 r/min.

feed rates 5 stages from 0.1 to 0.4 mm/r

drill spindle stroke 240 mm

working radius 400 mm

table dimensions 860 x 670 mm

diameter of column 200 mm

electrical data 380V / 5.5 KW

space requirements height - 2,300 x width - 900 x depth -
1,200 mm

-
