drilling capacity in steel 30 mm

drill spindle fixture MK 3

4 feed rate stages 0.1; 0.16; 0.25; 0.4 mm/r

spindle speed 6 stages from 85 to 1,500 r/min

drill spindle stroke 230 mm

working radius 330 mm

table dimensions 400 x 400 mm

rotary table pivotable right / left

column diameter 160 mm

electrical data 380V / 2.2 KW

space requirements height - 2,300 x width - 600 x depth -
850 mm

weight approx. 720 kg

-
